| Title | Description | Unit | Puma 280M |
| Capacity | Swing over bed | mm | 630 |
| Swing over Saddle | mm | 500 | |
| Recom. Machining Dia | mm | 255 | |
| Max. Machining Dia. | mm | 410 | |
| Max. Work Length | mm | 610 | |
| Bar working Dia. | mm | 76 | |
| Travels | X Axis | mm | 240 |
| Z Axis | mm | 620 | |
| Feed rates | Rapid Traverse X / Z | mm/min | 20 / 24 |
| Spindle | Chuck Dia. | mm | 250 |
| Speed Speed | Rpm | 3500 | |
| Spindle power | Kw | 22 | |
| Spindle nose | ASA A2# | A2-8 | |
| Spindle Bore Dia | mm | 86 | |
| Bearing Bore Dia. | mm | 136 | |
| Turret | No. of stations | num | 12 |
| OD Tool Height | mm | 25 | |
| Maximum boring bar dia. | mm | ø40 | |
| Indexing time | Sec | 0.15 | |
| Rotary tool spindle speed | Rpm | 5000 | |
| Tailstock | Quill Dia | mm | 100 |
| Quill travel | mm | 100 | |
| Taper | mm | MT-5 | |
| CNC system | Controller | – | Fanuc Oi-MB |
| Machine size | Dimension (L x W x H) | mm | 1670x3418x1800 |
| Machine weight (Approx) | kg | 5000 |
| Optional Accessories Available with Machine | |
| · 3 Tool Holder(1x Boring, 1x Turning, 1x Live)
· Tailstock · Coolant Tank |
· Inbuilt Transformer
· Leveling Pad |
