| Title | Description | Unit | |
| Travel | X- axis | mm | 500 |
| Y- axis | mm | 400 | |
| Z- axis | mm | 330 | |
| Spindle | Spindle nose | type | BT30 |
| Spindle speed | rpm | 24,000 | |
| Spindle Power | Kw | 5.5/3.7 | |
| Table | Table Dimensions | mm | 650×400 |
| Max. Loading Weight | Kg | 300 | |
| ATC | No. of Tools | Nos | 21 |
| Feed rate | Rapid Traverse of X, Y, Z axis | m/min | 48 x 48 x 48 |
| CNC System | Controller | – | |
| Machine size | Dimensions (L x W x H) (Approx.) | mm | 1600 x 2100 x 2350 |
| Machine weight (Approx.) | kg | 2200 |
|
Optional Accessories Available with Machine |
|
| · 24000rpm BT30 Spindle
· 21 tool ATC ·
|
· Leveling Pad |
.
