| Title | Description | Unit | J3 |
| Travel | X- axis | mm | 630 |
| Y- axis | mm | 400 | |
| Z- axis | mm | 400 | |
| Spindle | Spindle nose | type | HSK-A50 |
| Spindle speed | rpm | 16000 | |
| Table | Table Dimensions | mm | 400X400 |
| Max. Loading Weight | Kg | 400 | |
| ATC | No. Of Tools | Nos. | 30 |
| Feed rate | Rapid Traverse of X, Y, Z axis | m/min | 65/65/65 |
| CNC System | Controller | – | FANUC Professional L |
| Machine size | Dimensions (L x B x H) | mm | 5000x3000x2800 |
| Machine weight (Approx.) | kg | 6000 |
